NVIDIA Mellanox MC2207910-015 QSFP IB FDR 56Gb/s VPI Active Optical Cable 15m
Price: €150.00
Condition: Refurbished
In stock
Description
NVIDIA Mellanox MC2207910-015 QSFP Active Optical Cable with LEDs, FDR InfiniBand 56Gb/s and 56GbE VPI, 15m: This is a 15-meter active optical cable (AOC) designed for FDR InfiniBand 56Gb/s and 40/56GbE VPI links over QSFP. The MC2207910 series adds integrated LED link/activity indicators on each connector for fast at-rack diagnostics. The AOC integrates VCSEL optics on multi-mode fiber with QSFP connectors permanently terminated at both ends. This is NOT a passive copper DAC and NOT a single-mode LR transceiver assembly. Condition: Refurbished.
Engineering Context: The cable carries 56Gb/s aggregate as 4 lanes × 14Gb/s NRZ for FDR InfiniBand, and supports 40GbE / 56GbE Ethernet over the same QSFP interface in VPI mode. The integrated LEDs on each QSFP head provide visual link status without needing to consult the switch CLI — useful in dense racks during cable tracing, troubleshooting, and decommissioning. Power and signaling are delivered through the QSFP electrical interface; no separate optical transceiver pair is required.
Deployment & Use Cases: Used for inter-rack interconnects in HPC clusters running FDR InfiniBand and MPI fabrics, between top-of-rack and aggregation switches at distances DAC cannot serve. Particularly suited to environments where rapid physical-layer diagnostics matter — colocation cages, university research clusters, and managed-services racks where on-site staff need to confirm link state without a console session.
Technical Specifications:
- Connector: QSFP to QSFP (factory-terminated) with integrated link/activity LEDs
- Cable type: Active Optical Cable (AOC), VCSEL over multi-mode fiber
- Data rate: 56Gb/s FDR InfiniBand (4x14G NRZ); 40GbE / 56GbE Ethernet in VPI mode
- Length: 15m
- Protocol modes: InfiniBand FDR and Ethernet (VPI)
- Diagnostics: integrated LEDs on each QSFP head
- Hot-pluggable: Yes (via QSFP)
- Condition: Refurbished
Compatibility & Constraints: Compatible with Mellanox QSFP host ports on ConnectX-3 / ConnectX-3 Pro VPI HCAs and SwitchX / SwitchX-2 switches in FDR or VPI mode. As a factory-terminated AOC, mid-span splicing or breaking the cable is NOT supported. This cable is NOT a breakout cable and is NOT a 100GbE QSFP28 AOC. Vendor lock-in or DDM compliance on third-party non-Mellanox switches is not guaranteed.
Why TES: Sourced and tested by T.E.S IT-SOLUTIONS, a specialist B2B reseller of NVIDIA Mellanox enterprise networking hardware. Ships from EU stock with 1–3 business day handling.
Frequently Asked Questions
What is the MC2207910-015 NOT compatible with?
This is NOT a passive copper DAC and NOT a single-mode LR transceiver assembly. Confirm fitment against your platform before ordering MC2207910-015.
What condition is the MC2207910-015 supplied in, and who sells it?
The MC2207910-015 is supplied in Refurbished condition by T.E.S IT-SOLUTIONS from EU stock, with 1-3 business day handling and worldwide B2B shipping. See https://www.tes-itsolutions.com/product-page/mc2207910-015-mellanox-15m-fiber-cable-qsfp-ib-fdr-eth-56gb-s-vpi-support.
Are there deployment constraints on the MC2207910-015?
As a factory-terminated AOC, mid-span splicing or breaking the cable is NOT supported. This applies to MC2207910-015 specifically.
